Intermediate Modules

We are closely monitoring the situation with COVID-19 (coronavirus) and following the guidance of the Centers for Disease Control and Prevention (CDC) and federal, state and local health authorities. Learn more about the measures we have put in place.



Fluorescence Cube Turret and Fluorescence Module

ModelDimensionsWeight (g)*
NI-FLT6-E Motorized Epi-fluorescence Cube TurretDiagram2,500
NI-FLT6-I Intelligent Epi-fluorescence Cube TurretDiagram2,500
NI-FLT6 Epi-fluorescence Cube TurretDiagram2,500
NI-FLEI Epi-fluorescence AttachmentDiagram1,500
NI-BPU Back Port UnitDiagram2,500
CI-FL Epi-Fluorescence AttachmentDiagram2,000
D-FL Epi-Fluorescence AttachmentDiagram3,300
C-HGFIB HG 100W Adapter RDiagram450
TI2-F-FLTH-E Motorized HQ Epi Filter TurretDiagram
2,000
TI2-F-FLT-E Motorized Epi Filter TurretDiagram
1,700
TI2-F-FLT-I Intelligent Epi Filter TurretDiagram
1,400
TI2-P-FWB-E Motorized BA Filter WheelDiagram1,500
TI2-LA-FLL EPI-FL Module for Large FOVDiagram2,000
TI2-LA-FL EPI-FL ModuleDiagram1,700
TI2-LA-BF Fixed Main BranchDiagram1,400
TI2-F-FLS Simple Epi-FL AttachmentDiagram1,500
TI2-F-FSC Circular Field Stop SliderDiagram200
TI2-F-FSS Square Field Stop SliderDiagram200
TI2-F-FSR Rectangle Field Stop SliderDiagram200
ModelDimemsionsWeight (g)*
NI-LH Precentered LamphouseDiagram1,000
TI-A DIC Analyzer CubeDiagram100
D-DP DIC Rotatable PolarizerDiagram300
TI2-D-PD Pillar for Dia IlluminationDiagram 1
Diagram 2
4,500
TI2-D-LHLED LED Lamp House for Dia IlluminationDiagram900
TI2-C-CLWDA CLWDA Condenser AdapterDiagram90
TI-DF Dark-Field Condenser AdapterDiagram155
TE-C ELWD-S CondenserDiagram450
TC-C-TC Condenser TurretDiagram700
TI2-C-TC-I Intelligent Condenser TurretDiagram700
TI2-C-TC-E Motorized Condenser TurretDiagram700
MC-TMD2 ELWD Condener LensDiagram200
TI-C-LWD LWD Condener LensDiagram220
TI-C-CLWD CLWD Condener LensDiagram170
TI-C NAMC Condenser LensDiagram200
TI2-C-DICP-I Intelligent PolarizerDiagram200
TC-C-DICP DIC PolarizerDiagram200
TC-C-DICPNI NAMC/IMSI PolarizerDiagram100
TI2-C-DICA AnalyzerDiagram200

Intermediate Module

ModelDimensionsWeight (g)*
Y-IDP Double PortDiagram1,300
Y-IDP Double Port 0/100Diagram1,300
Y-IM Magnification ModuleDiagram1,300

Contact Arm

ModelDimensionsWeight (g)*
NIU-CAM Contact ArmDiagram1,500
NIE-CAM Contact ArmDiagram1,500
NI-SAM Standard ArmDiagram1,400

* Approximately
