Microscope Camera Control Unit

Discontinued Replaced by NIS-Elements L


Connectable camerasDS-Ri2, DS-Fi3
Live imageFULL (resolution emphasized), FAST (display frame rate emphasized)
Format: RGB 24bits
Exposure controlProgram AE/Focus AE/Manual AE, with AE lock function
Brightness adjustmentExposure mode AE: Exposure compensation adjustment,
Exposure mode manual AE: Exposure time or gain adjustment
Exposure meteringAverage metering, Peak hold metering
Exposure metering areaPosition/size variable
White balanceOne-push operation
Image correctionTone, sharpness, black level, hue, chroma, R/B adjustment, shading correction, special effect
Scene modeLED/halogen, biological/industrial/asbestos/standard
Custom: Up to 7 types can be registered
Recording formatColor space: sRGB
Still image: TIFF/JPEG/DICOM
Movie: AVI
Saving destinationInternal drive (flash memory 64GB, approx. 28GB available) /microSD/USB memory/SMB file server
Measurement/drawing/scaleMeasurement target: Point-to-point distance, perpendicular line length, angle, circle, distance between center points of two circles, area
Measurement unit calibration registration: Auto registration calibration by objective information setting (seven types registerable)
Manual registration calibration: Manual calibration/optical calibration by entering objective magnification (14 types registerable)
Drawing: Text, line, arrow, pen, marker, scale bar
Scale: Cross, glid line, X scale (cross scale), XY scale
Microscope control*Biological microscope: Ni-E/Ni-U/Ci-E
Industrial microscope: LV150NA/LV100DA-U/LV100NDA
Stereo microscope: SMZ25/SMZ18/SMZ1270i
Supported languageEnglish, Japanese
SecurityAnti-virus: McAfee Embedded Control is preinstalled. Programs that can run are restricted by the whitelist method
User login method: With DS-L4 user registration, login is possible by entering user ID and password
LCD display10.1-type wide WUXGA (1920×1200)
InterfaceUSB3.0 host port x1, USB2.0 port x4, Display Port, micro HDMI
LAN (IEEE 802.3 10/100/1000 Base-TX, IEEE 802.11 a/b/g/n), Bluetooth, micro SD card slot
Power supplyAC100-240V 50Hz/60Hz
Power consumption65W
DimensionsMain body: 265 x 188 x 10mm, Including extended cradle: 265 x 201 x 107 mm
WeightMain body: 630g (approx.), Including extended cradle: 1060g (approx.)
Operating environment5-35℃, 20-80% RH max. (without condensation)

*Please contact Nikon about compatible microscopes.
