CFI SR HP Apo
TIRF 100XAC Oil
Material Number MRD01997
Type Apochromat
Primary Technique Super-Resolution
Immersion Oil
Magnification 100X
Numerical Aperture 1.49
Working Distance 0.16–0.09
Cover Glass Thickness 0.13–0.19
CFI SR HP Apo
TIRF 100XAC Oil
Diagram
(mm)
Transmittance Graph
CFI SR HP Apo
TIRF 100XAC Oil
Brightfield recommended for best results
Darkfield
DIC suitable
Fluorescence (visible) recommended for best results
Fluorescence (UV) possible with visible light that has a longer wavelength than the excitation light used for DAPI
Fluorescence (NIR)
Polarizing suitable
Polarizing Type Simple POL
Phase Contrast Ring EXT PH4
Phase Contrast Type
CFI SR HP Apo
TIRF 100XAC Oil
Correction Collar ✓ compatible with Auto Correction Collar
Spring Loaded
Iris
Long Working Distance
Ti2-E PFS Compatible
CFI SR HP Apo
TIRF 100XAC Oil
Asbestos
Clear Tissue
Clinical / Laboratory
Confocal
Education
Laser Trapping / Tweezing
Multiphoton
SIM
STORM
Research
TIRF
Tissue Culture
