Specifications
Main body | ECLIPSE Ti2-E/Ti2-E/B*1 | ECLIPSE Ti2-A | ECLIPSE Ti2-U |
---|---|---|---|
Optical system | Infinity-corrected CFI60 | ||
Field number*2 | 22 with C-mount, 25 with F-mount | ||
Intermediate Magnification switching | Manual switching of 1.0x/1.5x (exchangeable from 1.5x to 2.0x) | ||
Status detection | - | ||
Bertrand lens | Manual in/out, and manual focus, Status detection | - | |
Output port | 4 Motorized positions Eyepiece 100%, left 100%, right 100%, eyepiece 20%/left 80% (Ti2-E/B: bottom 100%) |
4 Manual positions Eyepiece 100%, left 100%, right 100%, option (to eyepiece 20%/left 80% or eyepiece 20%/right 80%) |
|
Can add ports by use of back port unit and/or choice of tube base unit*3 | |||
Focusing unit | Motorized drive, Coarse/fine focus changeover, 10mm stroke, Minimum increments: 0.01μm, 0.02μm (with encoder control) | Manual drive, Coarse/fine focusing knob, 10mm stroke | |
Stage up | Available*4 |
Tube body | ECLIPSE Ti2-E/Ti2-E/B*1 | ECLIPSE Ti2-A | ECLIPSE Ti2-U |
---|---|---|---|
Binocular tube | Binocular S tube TC-T-TS (field number 22), Ergonomic ER tube TC-T-ER (field number 22) | ||
Motorized eyepiece tube base unit for external PH (TI2-T-BP-E) | Camera port (field number 16), Motorized PH turret with 4 motorized positions | - | |
Assist eyepiece tube base unit (TI2-T-BA) | Assist camera (field number 22), Status detection | - | |
Eyepiece tube base unit with port (TI2-T-BC) | Camera port (field number 16) | - | Camera port (field number 16) |
Transmitted illumination | ECLIPSE Ti2-E/Ti2-E/B*1 | ECLIPSE Ti2-A | ECLIPSE Ti2-U |
---|---|---|---|
Pillar for transmitted illumination (TI2-D-PD) | Condenser vertical stroke: 66mm, Backward tilting up to 25 degrees, With field diagram and refocusing mechanism 2 filter slot positions (4 filter position option is also available with Filter Slider for transmitted illumination (TI2-D-SF)) | ||
LED Lamphouse for dia illumination (TI2-D-LHLED) | High power LED | ||
Precentered Lamphouse (D-LH/LC) | 100W halogen bulb (pre-centered) |
Condenser | ECLIPSE Ti2-E/Ti2-E/B*1 | ECLIPSE Ti2-A | ECLIPSE Ti2-U |
---|---|---|---|
Motorized condenser turret (TI2-C-TC-E) | 7 motorized positions (ø37mm x4, ø39mm x3), LWD/ELWD/CLWD/NAMC condenser lenses are supported | - | |
Intelligent condenser turret (TI2-C-TC-I) | 7 manual positions (ø37mm x4, ø39mm x3), Status detection, LWD/ELWD/CLWD/NAMC condenser lenses are supported | - | |
Condenser turret (TC-C-TC) | 7 manual positions (ø37mm x4, ø39mm x3), LWD/ELWD/CLWD/NAMC condenser lenses are supported | ||
ELWD-S condenser turret (TE-C) | 4 manual positions, With ELWD condenser lens (NA0.3/O.D.=65) | ||
HNA condenser slider (TI2-C-SCH) | 2 manual positions (ø37mm x1, ø39mm x1), HNA dry lens/HNA oil lens are supported | ||
Condenser lens | LWD (O.D.=30mm, NA=0.52), ELWD (O.D.=75mm, NA=0.29), CLWD (O.D.=13mm, NA=0.72), HNA dry (O.D.=5mm, NA=0.85), HNA oil (O.D.=2mm, NA=1.4), NAMC (O.D.=44mm, NA=0.4) |
Stage | ECLIPSE Ti2-E/Ti2-E/B*1 | ECLIPSE Ti2-A | ECLIPSE Ti2-U |
---|---|---|---|
Motorized stage (TI2-S-SE-E, TI2-S-SS-E) | Stroke X: ±57mm, Stroke Y: ±36.5mm, Max drive speed: approx. 25mm/sec, Magnetic sample holder | - | |
Stage (TC-S-SR, TC-S-SRF) | Stroke X: ±57mm, Stroke Y: ±36.5mm, Adjustable stroke range (3 levels) with adjusting pin, Long/middle/short handle options available | ||
Gliding stage (TC-S-GS) | Stroke ø20mm |
Nosepiece | ECLIPSE Ti2-E/Ti2-E/B*1 | ECLIPSE Ti2-A | ECLIPSE Ti2-U |
---|---|---|---|
Perfect Focus Unit with motorized nosepiece for Auto Correction Collar (TI2-N-NDA-P) | 5 motorized positions, Simple waterproof structure | - | |
Motorized DIC sextuple nosepiece (TI2-N-ND-E) Perfect Focus Unit with motorized nosepiece (TI2-N-ND-P) Perfect Focus Unit with motorized nosepiece for MP (TI2-N-NDM-P) |
6 motorized positions, Simple waterproof structure | - | |
Intelligent DIC sextuple nosepiece (TI2-N-ND-I) | 6 manual positions, Status detection, Simple waterproof structure | - | |
Sextuple nosepiece (TI2-N-N), DIC sextuple nosepiece (TI2-N-ND) | 6 manual positions, Simple waterproof structure |
Epi-filter turret | ECLIPSE Ti2-E/Ti2-E/B*1 | ECLIPSE Ti2-A | ECLIPSE Ti2-U |
---|---|---|---|
Motorized epi filter turret (TI2-F-FLT-E, TI2-F-FLTH-E) | 6 motorized positions, Motorized shutter | - | |
Intelligent epi filter turret (TI2-F-FLT-I) | 6 manual positions, Manual shutter, Status detection*5 |
Filter wheel/shutter | ECLIPSE Ti2-E/Ti2-E/B*1 | ECLIPSE Ti2-A | ECLIPSE Ti2-U |
---|---|---|---|
Motorized BA filter wheel (TI2-P-FWB-E) | 7 motorized positions, High speed mode: 50ms, Low vibration mode: 100ms (movement time between adjacent positions) | - | |
Motorized shutter (NI-SH-E)*6 | 12ms to open/close |
Epi-fluorescence attachment | ECLIPSE Ti2-E/Ti2-E/B*1 | ECLIPSE Ti2-A | ECLIPSE Ti2-U |
---|---|---|---|
EPI-FL module (TI2-LA-FL), EPI-FL module for large FOV (TI2-LA-FLL) | Supports fiber illuminator; includes 2-position filter slider and aperture diaphragm | ||
Simple EPI-FL attachment (TI2-F-FLS) | Supports both fiber illuminator and lamp house; includes 3-position filter slider | ||
Field stop slider | Circular (TI2-F-FSC), rectangular (TI2-F-FSR), square (TI2-F-FSS) aperture options |
Control unit | ECLIPSE Ti2-E/Ti2-E/B*1 | ECLIPSE Ti2-A | ECLIPSE Ti2-U |
---|---|---|---|
Controller, display device | Stage joystick (TI2-S-JS), Tablet | Tablet | - |
Controller for TI2-E (TI2-CTRE) | USB/LAN interface, I/O function | - |
Operating environmental | ECLIPSE Ti2-E/Ti2-E/B*1 | ECLIPSE Ti2-A | ECLIPSE Ti2-U |
---|---|---|---|
Temperature: 0℃+40℃, Humidity: 60% RH max. (at +40℃, no condensation), Indoor use only |
Motorized accessories have a status detection function
*1 Motorized model with a bottom port
*2 Limitations apply based on objective and filter cube choice, stage-up configuration, and illumination module, etc.
*3 Tube base units with a port cannot be used with Ti2-A
*4 Stage up kit is required. Please contact Nikon.
*5 Status detection cannot be used when attached to the Ti2-U
*6 NI-SH-CON Controller for Motorized Shutter is required for use with the Ti2-A/Ti2-U
Dimensions
